SMT Inductors B82432T1332K000

　　SMT inductors

　　SIMID series, SIMID 1812-T

　　Series/Type: B82432T

　　Size 1812 (EIA) or 4532 (IEC)

　　Rated inductance 1μH to 1000μH

　　Rated current 70 mA to 1300 mA

　　Construction

　　■ Upright ferrite drum core

　　■ Laser-welded winding

　　■ Flame-retardant molding

　　Features

　　■ Temperature range up to 150 °C

　　■ High current handling capability

　　■ Qualified to AEC-Q200

　　■ Suitable for lead-free reflow soldering

　　as referenced in JEDEC J-STD 020C

　　■ RoHS-compatible

　　Applications

　　■ Filtering of supply voltages, coupling, decoupling

　　■ DC/DC converters

　　■ Automotive electronics (e.g. single-wire bus systems)

　　■ Telecommunications

　　■ Industrial electronics

　　Terminals

　　■ Base material CuSn6

　　■ Layer composition Cu, Ag, Sn (lead-free)1)

　　■ Electro-plated

　　Marking

　　■ Marking on component:

　　Manufacturer and letter “T”,

　　L value (in μH), tolerance of L value (coded),

　　date of manufacture (YWWD)

　　■ Minimum data on reel:

　　Manufacturer, ordering code, L value, quantity, date of packing

　　Delivery mode and packing unit

　　■ 12-mm blister tape, wound on 330-mm ? reel

　　■ Packing unit: 2500 pcs./reel
